Description:
e HEF4093B is a quad two-input NAND gate. Each input of HEF4093B has a Schmitt trigger circuit. The gate switches at different points for positive-going and negative-going signals. The difference between the positive voltage (VT+) and the negative voltage (VT_) is defined as hysteresis voltage (VH).
HEF4093B operates over a recommended VDD power supply range of 3 V to 15 V referenced to VSS
(usually ground). Unused inputs must be connected to VDD, VSS, or another input.
MD0365RL Green Mode Fairchild Power Switch Features:
Schmitt trigger input discrimination
Fully static operation
5 V, 10 V, and 15 V parametric ratings
Standardized symmetrical output characteristics
Operates across the automotive temperature range from -40 °C to +125 °C
Complies with JEDEC standard JESD 13-B
Application:
Wave and pulse shapers
Astable multivibrators
Monostable multivibrators
Package included:
- 1 X MD0365RL Green Mode Fairchild Power Switch
