original New Acer Aspire 8930G Geforce 9700MGT 9700M GT G96-750-A1 DDR3 512MB MXM III Graphic VGA Video Card  VG.9EG06.001

Product Description

   30 Days DOA Warranty



The Nvidia GeForce 9700M GT is a DirectX 10 graphics card for notebooks and successor to the 8700M GT. Technically, the 9700M GT is a higher clocked version of the 9600M GT. It is produced in 65nm (allows higher clock rates with the same current consumption) and features a new PureVideo HD video processor (VP3) and HybridPower support.

In conjunction with the Nvidia 9100M G integrated graphics, the 9700M GT supports Hybrid-SLI (only HybridPower). HybridPower is a technique to choose between the integrated and dedicated graphics core, if performance or battery runtime is needed. This works only in Windows Vista. Up to now the user has to use a tool to switch between the GPUs. Later Nvidia wants to switch automatically in the drivers. GeForceBoost is not supported with this card, as there would be no performance gain.

As the 9600M GT and 8700M GT, the 9700M GT features 32 stream processors that do the graphic work of the vertex- and pixel-shaders (which are higher clocked than the core with 1550 MHz).

The performance of the 9700M GT is clearly above the 9600M GT because of the high clock speed (highest current clockspeed of the 9000M series). Still demanding DirectX 10 games, like Crysis wont run fluently with high details and high resolutions.

Compared to desktop graphics cards, the 9700M GT is similar to the GeForce 9500GT (which also descends from the G96 core).

New Acer Aspire 8930G Geforce 9700MGT 9700M GT G96-750-A1 DDR3 512MB MXM III Graphic VGA Video Card  VG.9EG06.001 Features

==========================================

Acer MXM Models and Cards
So, you've probably heard it told to you time and time and time again, that there is no way to upgrade a dedicated GPU on a notebook.
But as an Acer owner, you may very well be among the lucky few who CAN upgrade their GPU, since Acer used the MXM standard on its notebooks for quite a few models - unfortunately, it seems that as of mid-2010, they've returned to embedded the discrete GPU into the mainboard, effectively cutting off the MXM standard.
(For a primer on what MXM is, go have a look at the best resource online for MXM.)

EDIT: But if your system came with any Intel GMA, it cannot be upgraded. NO EXCEPTIONS.

This topic will list which notebooks are CONFIRMED to be MXM-capable, as well as what slot they have, and what cards they were originally sold with (consider those safe upgrades). Any successful new-card upgrades will be linked to alongside the model.
A later post will document all the MXM cards that Acer has issued - although it's possible to use cards from other vendors, it's safest and more likely to be compatible if you stick with an Acer issue.

EDIT: That being said, MXM-Upgrade.com is willing to provide a money-back guarantee on their cards if it proves to be incompatible with your machine. Hit them up here!

LAST UPDATE: May 7, 2011
IT WORKS! .NetRolller 3D's brilliant scheme to fix the x920G/9600M GT compatibility issue had its first successful trial - lizzarddos was the brave soul. Have a gander, and be in awe.

Note: Due to new data, the validity of prior research has been called into question. Italicized models have not been confirmed with an Acer service guide, nor have they ever been upgraded. Please consider them as possibly wrong until further notice.

Aspire 4520G - MXM-II, 8400M G, 8400M GS, Upgrade to 8600M GS Upgrade to 8600M GT
Aspire 4710G - MXM-II, HD 2400XT, Upgrade to 8600M GT
Aspire 4720G - MXM-II, 8400M G
Aspire 4920G - MXM-II, HD 2400XT, Upgrade to HD 3650
Aspire 5520G - MXM-II, 8400M G, 8400M GS, 8600M GS, 9300M G, Upgrade to 8600M GT, Upgrade to 9650M GT
Aspire 5530G - MXM-II, HD 3470, HD 3650, Upgrade to 9600M GT
Aspire 5710G - MXM-II, Upgrade to HD 3650
Aspire 5720G - MXM-II, 8400M GS, 5720ZG Upgrade to HD 2600, Upgrade to 9500M GS, Upgrade to HD 3650, Upgrade to 9650M GT, Upgrade to 9600M GT
Aspire 5920G - MXM-II, 8600M GS, 8600M GT, 9500M GS, HD 3470 Upgrade to HD 3650, Upgrade to HD 4650 (Second), Downgrade to X1700, Upgrade to HD 4670, Upgrade to 9650M GT [Note: The 9600M GT is NOT compatible with the 5920G]
Aspire 5930G - MXM-II, 9300M GS, 9600M GT
Aspire 6530G - MXM-II, HD 3470, HD 3650, HD 4570, HD 4650, Failed Upgrade to 9600M GT
Aspire 6920G - MXM-II, 9500M GS, HD 3650, Upgrades to 9600M GT: Partial Success, Full Success with modded BIOS, Upgrade to 9600M GS, Upgrade to HD 4650, Upgrade to HD 4670
Aspire 6930G - MXM-II, 9300M GS, 9600M GS, 9600M GT, HD 4650, Upgrade to 8600M GT
Aspire 6935G - MXM-II, 9600M GT, Upgrade to HD 4650
Aspire 7520G - MXM-II, 8400M G, 8600M GS, Upgrade to 8600M GT, Upgrade to HD 3650, Upgrade to HD 2400 XT, Upgrade to HD 3470, Failed Upgrade to HD 2600
Aspire 7720G - MXM-II, 8400M GS, 9300M G, 9300M GS, 9500M GS, Upgrade to 9600M GT, Upgrade to 9650M GT, Upgrade to HD 3470 (7720ZG)
Aspire 7730G - MXM-II, 9300M GS, 9600M GT
Aspire 8530G - MXM-II, HD 3470, HD 3650
Aspire 8730G - MXM-II, 9300M GS, 9600M GT
Aspire 9920G - MXM-II, 8600M GT
Extensa 4630G - MXM-I(II?), 9300M GS
Extensa 5420G - MXM-II, HD 2400XT
Extensa 5610G - MXM-II, X2500, HD 2300
Extensa 5620G - MXM-II, X2500, HD 2400XT
Extensa 5630G - MXM-II, HD 3470, 9300M GS
Extensa 7620G - MXM-II, HD 2400XT
TravelMate 4730G - MXM-II, 9300M GS
TravelMate 5520G - MXM-II, X2500, HD 2400XT, HD 2600
TravelMate 5530G - MXM-II, HD 3470, Upgrade to HD 3650
TravelMate 5710G - MXM-II, X2500, HD 2300
TravelMate 5720G - MXM-II, HD 2400XT, X2500, HD 2600 Failed Upgrade to 8400M GS
TravelMate 5730G - MXM-II, HD 3470, 9300M GS
TravelMate 6593G - MXM-II, HD 3470
TravelMate 7520G - MXM-II, HD 2400XT, HD 2600
TravelMate 7530G - MXM-II, HD 3470
TravelMate 7720G - MXM-II, 8400M GS, HD 2400XT, X2500, HD 2600, Upgrade to 8600M GT, Failed Upgrade to HD 4650
TravelMate 7730G - MXM-II, 9300M GS, HD 3470, 9600M GT

Aspire 8920G - MXM-III, 9500M GS, HD 3650, 9650M GS, Upgrade to 9600M GT (Partial Success), Upgrade to 9600M GS
Aspire 8930G - MXM-III, 9600M GS, 9600M GT, 9700M GT, Upgrade to 9650M GT

Aspire 5739G - MXM-A, HD 4570, GT 130M, GT 240M, Upgrade to HD 4650, Upgrade to HD 4670
Aspire 5935G - MXM-A, HD 4570, GT 130M, Upgrade to HD 4670, Upgrade to GT 240M, Upgrade to GTS 250M
Aspire 5940G - MXM-A, HD 4570, GT 130M
Aspire 7735G - MXM-A (verified with photo), HD 4570, Upgrade to GT 130M
Aspire 7738G - MXM-A, GT 130M, GT 240M, Upgrade to HD 4670
Aspire 8735G* - MXM-A, GT 240M
Aspire 8935G* - MXM-A, HD 4650, HD 4670, GT 130M, Upgrade to GTS 250M
Aspire 8940G* - MXM-A, GT 240M, GTS 250M

*Although there appears to be room in the chassis and motherboard for an MXM-B board, the heatsink design is not able to cover the MXM-B's memory chip placement.

Aspire 4935G - Checked service guide, GPU is embedded in motherboard.
Aspire 4937G - Posted here, GPU is embedded in motherboard.
Aspire 5536G - Checked service guide, GPU is embedded in motherboard.
Aspire 5738G - Checked service guide, GPU is embedded in motherboard.
Aspire 5741G - Checked service guide, GPU is embedded in motherboard.
Aspire 5745G - Checked service guide, GPU is embedded in motherboard.
Aspire 5942G - Checked service guide, GPU is embedded in motherboard.
Aspire 5943G - Checked service guide, GPU is embedded in motherboard.
Aspire 8942G - See here, confirmed by service guide.
Aspire 8943G - Checked service guide, GPU is embedded in motherboard.

DISCLAIMER: I am not responsible for any damages to your notebook's functionality by using the information provided here. Proceed at your own risk.

Package Content

New Acer Aspire 8930G Geforce 9700MGT 9700M GT G96-750-A1 DDR3 512MB MXM III Graphic VGA Video Card  VG.9EG06.001 x 1
