ATI Mobility Radeon HD 4670

The ATI Mobilty Radon HD 4670 from for AMD is a DirectX 10.1 middle-class notebook graphics adapter. Technically it is a higher clocked Mobility Radeon HD 4650. The 4670 was later renamed to Mobility Radeon HD 565v and succeeded by theMobility Radeon HD 5650 (DX 11 Support and a higher shader count but lower clocked).

The gaming performance of the GPU lies between the desktop HD 4650 and 4670. Therefore, most DirectX 9 games (like Call of Duty 4, F.E.A.R., or Unreal Tournament 3) should be playable in high details (in 1024x768). Demanding DX10 games from 2008 like Crysis run only in medium details fluently. Compared to Nvidia graphics cards, the performance should be on par with a GeForce GT 335M (lower synthetic scores but equal gaming performance).

The Mobility HD 4670 is based on the RV730 chip and features 320 stream processors (64 5-dimensional shader cores). These cores do the graphic work of the shader- and pixel pipelines of older GPUs. The stream processors are also called ALUs and are grouped in five-way VLIW units. Each of the five instructions of a VLIW bundle has to be independent from the others and therefore the performance depends on the optimization of the driver.

A speciality of the Radeon HD 4600 Series is the possibility to use ordinary DDR2 and DDR3 graphic memory (as a cheaper alternative to GDDR3). However, cards that use that kind of memory will be slower than others equipped with GDDR RAM.

The Mobility Radeon HD 4670 includes the Avivo HD called video technology including an onboard soundchip for 7.1 sound output over HDMI or DisplayPort and the 2nd generation UVD (Unified Video Decoder). This UVD 2 supports full bitstream decoding of H.264/MPEG-4 AVC and VC-1 streams. In addition to this, it also supports dual video stream decoding and Picture-in Picture mode which makes the UVD full BD-Live compliant. Simplified, the Avivo HD technology handles all video tasks and enables the GPU to decode HD videos.

for AMD published a current consumtion of about 28-30 Watt for the HD 4670. Still it is unclear if this value represents the chip alone or the whole mxm board including the memory (which would include about 5 Watt). Nevertheless, the battery runtime should be compareable to a laptop with GeForce 9600M GT / GT 130M graphics adapter.

Compared to the desktop ATI Radeon HD 4670, the mobile counterpart features a slower chip and memory clock (675/800 versus 775/900-1000) and therefore performs somewhere between a desktop 4650 and 4670.
