Original Best HP Pavilion DV6 Series 15.6" Laptop for AMD Radeon HD 6770 6770M HD6770M GDDR5 1GB Graphics Video Card MXM VGA Board Replacement

$28.99

  • Model: HP-HD6770M
  • Units in Stock: 158


Free shipping

Description

Original Best HP Pavilion DV6 Series 15.6" Laptop for AMD Radeon HD 6770 6770M HD6770M  GDDR5 1GB Graphics Video Card MXM VGA Board Replacement Free Shipping



Not New , Taken from for iMac Desktop

tested in full working condition before shipping.

Three Months Warranty



Product Description



    • Manufacturer: AMD
    • Condition: Used
    • Model: HD 6770M

  • Comes with the card only, without any accessaries like the headsink or drive disc



Original Best HP Pavilion DV6 Series 15.6" Laptop for AMD Radeon HD 6770 6770M HD6770M  GDDR5 1GB Graphics Video Card MXM VGA Board Replacement

AMD Radeon HD 6770M



The for AMD Radeon HD 6770M (sometimes also called ATI Mobility Radeon HD 6770 or similar) is a fast middle class graphics card for laptops in 2011. It supports DirectX11, is the successor of the HD 5770, and features higher clock rates, 80 more shaders, Eyefinity+ and the new UVD3 video decoder. However, it is still produced in 40nm and based on the same Whistler chip as the entire 6700M and 6600M series. The chip is normally clocked at 725 MHz, but is only clocked at 675 MHz in the MacBook Pro 15 Late 2011 model.

The 480 Stream processors should still based on the "old" 5D architecture similar to the 5000 series. Therefore, the number of shaders is not comparable to the 1D cores of current Nvidia GPUs. The Tessellation performance, however, should be an improvement with the new cards. The Stream processors can be used with DirectX 11, OpenGL 4.1, DirectCompute 11 and OpenCL. The latter two APIs can exploit the GPU for general computations like transcoding videos.

The 3D performance of the 6770M is slightly better than the GeForce GT 555M and is therefore positioned in the upper middle class as of 2011. Demanding games like Anno 2070 or Skyrim can only be played in medium detail settings and lower resolutions. Certain games, such as Battlefield 3, may even only run in low detail settings. Older games like Call of Duty: Black Ops are playable with all settings maxed.

The new UVD3 video decoder supports the decoding of MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash and now also Multi-View Codec (MVC) and MPEG-4 part 2 (DivX, xVid) HD videos on the graphics card.

Furthermore, the HD 6700M series integrates an HD audio controller to transmit HD Audio (TrueHD or DTS Master Audio) over HDMI and DisplayPort (e.g., for Blu-Ray videos).

The for AMD HD3D Technology offers support for Blu-Ray 3D and 3D displays (integrated and external). However, the solution is not as mature as 3D Vision from Nvidia in terms of dirvers and overall support.

Thanks to Eyefinity, the for AMD card is able to theoretically drive up to 5 monitors simultaneously. This would only work, however, if the laptop features enough DisplayPort outputs.

The power consumption of the 6770M should be similar to the Mobility Radeon HD 5770. As a result, the 6770M is normally only found in 15-inch or larger notebooks.



Original Best HP Pavilion DV6 Series 15.6" Laptop for AMD Radeon HD 6770 6770M HD6770M  GDDR5 1GB Graphics Video Card MXM VGA Board Replacement Features





Manufacturer

AMD

Radeon HD 6600M/6700M Series

Radeon HD 6770M

480 @ 675 / 725 MHz

128 Bit @ 800 MHz

Radeon HD 6750M

480 @ 600 MHz

128 Bit @ 900 MHz

Radeon HD 6730M

480 @ 725 MHz

128 Bit @ 800 MHz

Radeon HD 6650M

480 @ 600 MHz

128 Bit @ 900 MHz

Radeon HD 6630M

480 @ 485 MHz

128 Bit @ 800 MHz

Codename

Whistler-XT

Architecture

Terascale 2

Pipelines

480 - unified

Core Speed *

675 / 725 MHz

Memory Speed *

800 MHz

Memory Bus Width

128 Bit

Memory Type

GDDR5

Shared Memory

no

DirectX

DirectX 11, Shader 5.0

Transistors

716 Million

technology

40 nm

Notebook Size

medium sized

Date of Announcement

04.01.2011

 Remark:

1. The MXM card tested in laptop & 3D mark befor sent.

2. Some of Laptop need updated bios & compatible it.

3. If the MXM card driver conflict with some device driver in laptop, the operate system maybe need re-install.

4. Pls paste the heat-sink sticker as below photo before install the card

5. come with the card only, without any accessaries like the headsink or drive disk.



Package Content



Original Best HP Pavilion DV6 Series 15.6" Laptop for AMD Radeon HD 6770 6770M HD6770M  GDDR5 1GB Graphics Video Card MXM VGA Board Replacement  Free Shipping x 1



Additional Information

  • Model: HP-HD6770M
  • Shipping Weight: 0.1kg
  • 158 Units in Stock

Reviews: 0


There are currently no product reviews.
NOTE: Reviews require prior approval before they will be displayed



This product was added to our catalog on Monday 22 April, 2024.
