System Interface

Data transfer speed

Max. 150 MB/s

Performance

CD

Key: insert "Max X" speed for each media below. For CD 1X=150 KB/s; DVD 1X=1350 KB/s; BD 1x = 4.5 MB/s

Read

�Max.24X

Digital Audio Extraction (DAE)

�Max.20X

Write CD-R

�Max.16X

Write CD-RW

�Max.10X

DVD

Read (Single Layer / Dual or Double Layer)

�Max. 8X/6X

Write DVD+R Double Layer

�Max.2.4X

Write DVD-RAM

�Max.5X

Write DVD+RW

�Max.4X

Write DVD-RW

�Max.4X

Power Consumption

Typical

�1100 mA

Acoustic noise

Operating (Sound pressure level, typical)

�less than 50 dBA

Power supply

Voltage

�DC5V +/-0.25V

Temperature

Operating� C (F)

�5 ~ 50 �C (41 ~ 122 �F)

Non-operating C (F)

�-40 ~ 65 �C (-40 ~ 149� �F)

Relative Humidity

Operating (No condensation)

�10 ~ 90%

Non-operating (No condensation, Power Off, without disc)

� 5 ~ 95%

Altitude

Operating m (ft)

�-200m ~ 3,048m (-656 ~ 10000ft)

MTBF:

�60,000h (Duty:20%)

Dimensions and weight

Width mm (in)

�128 mm (5.04 in)

Depth mm (in)

�129.0 mm (5.08 in)

Height mm (in)

�9.5 mm (0.37 in)

Weight g

�140g +/-10g
