Sanyo DL-4038-021 Laser Diode 635nm 10mw 9MM High Power AlGaInP Laser Diode

Description:

DL-4038-021 is a high power 635 nm (Typ.) AlGaInP laser diode with low threshold current. High output power and low threshold current are achieved by use of a strained quantum well active layer. The lasing wavelength is the same as that of the He-Ne gas lasers. DL-4038-021 is suitable for applications such as laser printers, line markers and other optical information systems.

Features:

• Short wavelength : 635 nm (Typ.)
• High output power : 10mW CW
• Low threshold current : Ith = 35 mA (Typ.)
• Low operating voltage : Vop = 2.2 V (Typ.)

Application:

• Laser printers
• Line markers and
• Other optical information systems.

• Package Included:

1 X Sanyo DL-4038-021 Laser Diode 635nm 10mw 9MM High Power AlGaInP Laser Diode
